Off-grid Solar Power Systems
Off Grid Power Systems:
Solar Ready Battery System  Stand Alone

Components of Off-Grid Systems

Off grid or autonomous solar systems are installed in remote locations where utility grid access is
limited or impossible. It is also commonly employed in the areas where power grid access is
expensive or where there is continuous risk of blackouts. Additionally, autonomous solar systems
that are installed on boats and RVs require an independent power solution.

Typically off grid systems require a larger up-front investment than grid tied systems due to additional
charge controller and batteries that are employed in the system. Please note that in an off-grid
system, only off grid inverters should be used. In compensation for these additional upfront costs,
owners are provided with independence and a feeling of self reliance.

The power that is generated by the renewable energy source initially charges the batteries through
the charge controller. The inverter helps to regulate the voltage and in most cases converts the DC
power to AC (what normal home appliances require). Most RVs and boats do not require an inverter
since appliances are suitable for DC current.

It should be noted that at a site where regular power blackouts are common, an off-grid system is the
best solution. A grid-tied system will shut off during the blackout due to safety reasons.
$509.60
$930.00
Free Shipping
Free Shipping
$0000
$0000
Free Shipping
Free Shipping
100 Watt Off Grid Mini Kit (12V)
Include:
(1) 100 watt solar panel.
(1) Charge Controller
(1) 12 V 110 AMP HOUR, AGM Battery
20' #10AWG Output Cable (PANEL to
CONTROLLER)
14" #10AWG Cable/ With Ring Terminal in one
end (CONTROLLER to BATTERY)

WIRING DIAGRAM Download
200 Watt Off Grid Mini Kit (12V)
Include:
(2) 100 watt solar panel.
(1) Charge Controller
(2)  12 V 110 AMP HOUR, AGM Battery
20' #10AWG Output Cable (PANEL to
CONTROLLER)
14" #10AWG  Cable/ With Ring Terminal in one
end (CONTROLLER to BATTERY)
14" #10 AWG  Cable / With Ring Terminal in both
ends (BATTERY to BATTERY)
WIRING DIAGRAM Download
400 Watt Off Grid Starter Kit
(12V)
Include:
(2) 200 watt solar 12V panel.
(1) PS 30M (w/meter) ProStar 30 Charge
Controller with meter
(3)  12 V 110 AMP HOUR, AGM Battery
20' #10AWG Output Cable (PANEL to
CONTROLLER)
14" #10AWG  Cable/ With Ring Terminal in one
end (CONTROLLER to BATTERY)
14" #10 AWG  Cable / With Ring Terminal in both
ends (BATTERY to BATTERY)
$0000
$0000
Free Shipping
Free Shipping
$0000
$0000
Free Shipping
Free Shipping
570 Watt  Cabin Kit (24V)
Include:
(3) 190 watt solar panel.
(1) PS 15M (w/meter) ProStar 15 Charge
Controller with meter
(4)  12 VOLT DC, 110 AMP HOUR,Universal Solar
20' #10AWG Output Cable (PANEL to
CONTROLLER)
14" #10AWG Cable/ With Ring Terminal in one
end (CONTROLLER to BATTERY)
1140 Watt  Cabin Kit (24V)
Include:
(6) 190 watt solar panel.
(1) PS 15M (w/meter) ProStar 15 Charge Controller
with meter
(8)  12 VOLT DC, 110 AMP HOUR,Universal Solar
20' #10AWG Output Cable (PANEL to
CONTROLLER)
14" #10AWG  Cable/ With Ring Terminal in one
end (CONTROLLER to BATTERY)
14" #10 AWG  Cable / With Ring Terminal in both
ends (BATTERY to BATTERY)
1520 Watt  Small Home  (24V)
Include:
(8) 190 watt solar 12V panel.
(1) PS 30M (w/meter) ProStar 30 Charge
Controller with meter
(6)  12 VOLT DC, 200 AMP HOUR,Universal Solar
20' #10AWG Output Cable (PANEL to
CONTROLLER)
14" #10AWG  Cable/ With Ring Terminal in one
end (CONTROLLER to BATTERY)
14" #10 AWG  Cable / With Ring Terminal in both
ends (BATTERY to BATTERY)
600 Watt Off Grid Starter Kit
(12V)
Include:
(3) 200 watt solar 12V panel.
(1) PS TriStar TS-45 Charge Controller
(4)  12 VOLT DC, 110 AMP HOUR,Universal Solar
20' #10AWG Output Cable (PANEL to
CONTROLLER)
14" #10AWG  Cable/ With Ring Terminal in one
end (CONTROLLER to BATTERY)
14" #10 AWG  Cable / With Ring Terminal in both
ends (BATTERY to BATTERY)
1900 Watt  Small Home (24V)
Include:
(10) 190 watt solar 12V panel.
(1) PS 30M (w/meter) ProStar 30 Charge
Controller with meter
(8)  12 VOLT DC, 200 AMP HOUR,Universal Solar
20' #10AWG Output Cable (PANEL to
CONTROLLER)
14" #10AWG  Cable/ With Ring Terminal in one
end (CONTROLLER to BATTERY)
14" #10 AWG  Cable / With Ring Terminal in both
ends (BATTERY to BATTERY)
